      - Electrical
Input Voltage: AC90~240V, 50~60Hz ± 10%
Max. Power: 10W (MAX)
Signal
Band: 2.402GHz – 2.480GHz, ISM, 79 channels
Spread spectrum: FHSS, 1100 hops / sec
Modulation: GFSK
Maximum Transmit Power: 23dBm
Receiver Sensitivity: -94dBm
Physical
Dimensions: 260 x 76 x 72mm
Net Weight: 0.8Kg
Surface Treatment: Aluminum, high temperature black paint
Housing Color: Black (Can be customized)
Connection: DMX signal IN/OUT, Power CON IN/OUT
Certification and Safety
Operating Environment: Indoor
Working Temperature:-10°C～40°C
|
