         - Electrical
Input Voltage: AC90~240V, 50~60Hz ± 10%
Max. Power: 400W (MAX)
Fuse: AC250V/5A
Light Source
LED Type: 37pcs ×10W CREE XML white super bright LED
Drive Current: 3000mA
Colors: White
Life: 100,000 hours
Control
Control Protocol: International standard DMX-512 signal
Channel Protocol: 2 channel modes. 1CH P1 and 3CH P2 modes can be chosen
Control Mode: DMX-512, auto, master-slave mode, static mode and LED
Optical System
Dimming mode: Dimmer 0 means fast Linear dimming. Dimmer 1~9 stands for soft Non-linear dimming
Dimmer: From 0~100 linear dimming
Strobe: 1~20Hz
Beam angle: 25°(Or 8°)
Lens: Honeycomb type high transparent PMMA second optical lens
Physical
Dimensions: 430 x 268 x 268mm
Net Weight: 6.1Kg
Surface Treatment: Die-casting aluminum, high temperature black paint
Housing Color: Black (Can be customized)
Connection: DMX signal IN/OUT, Power Con IN/OUT
Certification and Safety
Cooling System: Fan
Temperature protection: 65°C
Operating Environment: Indoor
Working Temperature:-20°C～40°C
