LD103-1210CW(led wall washer light)

Power supply
Voltage: DC240V, 500mA
Power: 50W

LED
LED Type: 12×10Watt CREE MCE  Cold / Warm White 4IN1 super bright LED
Drive Current: 500mA
Color Temp: CW 6000~6500K, WW 2700~2900K

Life: 50,000 hours

Optical System
Dimming Mode: Dimmer 0 means fast Linear dimming. Dimmer 1~9 stands for soft Non-linear dimming

Dimmer: From 0~100 linear dimming
Strobe: 1~20Hz

Lens: Honeycomb type high transparent PMMA second optical lens
Beam Angle: 25° (Or 40°)

Physical
Dimensions: 610 x 80 x 118 mm
Net Weight: 1.8 kg
Surface Treatment: Stretched aluminum, the surface anodic oxidation
Housing Color: Black (Can be customized)
Connection: DMX cable IN

Security
Cooling System: Convection

Temperature Protection: 65°C
Operating Environment: Indoor
Working Temperature: -20°C～40°C

Controller (YO-LD103-1F)

Power supply

Voltage: AC90~240V
Frequency: 50~60Hz ± 10%
Power: 600W

Control
Control Protocol: International standard DMX-512 signal
Channel Mode: 3 control channel modes. 2CH MODE1, 3CH MODE2, 24CH MODE3 mode can be chosen
Control Mode: DMX-512, auto, static mode and LD008 control mode
Auto Effect: 7 kinds of auto effect

Control Address Code: 512 DMX, 255 ID

Signal Output: 12 drive signal output, output current 700mw X 2

Physical
Dimensions: 482 x 256 x 88 mm
Net Weight: 6.9 kg
Surface Treatment: Stretched aluminum, the surface anodic oxidation
Housing Color: Silver (Can be customized)
Connection: DMX cable IN/OUT, POWER cable IN/OUT

Security
Cooling System: Convection

Temperature Protection: 65°C
Operating Environment: Indoor
Working Temperature: -20°C～40°C
