Power supply
Voltage: AC90~240V
Frequency: 50~60Hz ± 10%
Power: 130W
LED
LED Type: 12×10Watt RGBW 4IN1 full color super bright LED
Drive Current: 500mA
Colors: 16.7 million colors (0~100% saturation dimming)
Life: 50,000 hours
Control
Control Protocol: International standard DMX-512 signal
Channel Mode: 6 control channel modes. RGBW, RGBW+D, RGBW+S, RGBW+S+ID, RGBW+SP+ID, HSV mode can be chosen
Control Mode: DMX-512, auto, master&slave, static mode and LD008 control mode
Auto Effect: 16 kinds of editing custom auto effect
Control Address Code: 512 DMX, 255 ID
Optical System
Dimming Mode: Dimmer 0 means fast Linear dimming. Dimmer 1~9 stands for soft Non-linear dimming
Dimmer: From 0~100 linear dimming
Strobe: 1~20Hz
Lens: Honeycomb type high transparent PMMA second optical lens
Beam Angle: 25° (Or 40°)
Physical
Dimensions: 1000 x 80 x 118 mm
Net Weight: 3.66 kg
Surface Treatment: Stretched aluminum, the surface anodic oxidation
Housing Color: Black (Can be customized)
Connection: DMX cable IN/OUT, POWER cable IN/OUT
Security
Cooling System: Convection
Temperature Protection: 65°C
Waterproof Grade: IP65
Operating Environment: Indoor / Outdoor
Working Temperature: -20°C～40°C
Optional Accessories: Yoline LED controller (YO-LD008-1A)
