Power supply
Voltage: AC90~240V
Frequency: 50~60Hz ± 10%
Power: 130W
LED
LED Type: 12×10Watt RGBW 4IN1 full color super bright LED
Drive Current: 500mA
Colors: 16.7 million colors (0~100% saturation dimming)
Life: 50,000 hours
Control
Control Protocol: International standard DMX-512 signal
Channel Mode: 4 control channel modes. 4CH P1, 6CH P2, 9CH P3, 4CH P4 mode can be chosen
Control Mode: DMX-512, auto, master&slave, static mode and LED
Auto Effect: 9 kinds of static effect, 3 kinds of dynamic effect
Control Address Code: 512 DMX, 255 ID
Optical System
Dimming Mode: Dimmer 0 means fast Linear dimming. Dimmer 1~9 stands for soft Non-linear dimming
Dimmer: From 0~100 linear dimming
Strobe: 1~20Hz
Lens: Honeycomb type high transparent PMMA second optical lens
Beam Angle: 25° (Or 40°)
Physical
Dimensions: 610 x 80 x 118 mm
Net Weight: 2.66 kg
Surface Treatment: Stretched aluminum, the surface anodic oxidation
Housing Color: Black (Can be customized)
Connection: DMX cable IN/OUT, POWER cable IN/OUT
Security
Cooling System: Convection
Temperature Protection: 65°C
Operating Environment: Indoor
Working Temperature: -20°C～40°C
