Power supply
Voltage: AC90~240V
Frequency: 50~60Hz ± 10%
Power: 80W
LED
LED Type: 24×3Watt RGB 3IN1 full color super bright LED
Drive Current: 350mA
Colors: 16.7 million colors (0~100% saturation dimming)
Life: 50,000 hours
Control
Control Protocol: International standard DMX-512 signal
Channel Mode: 7 control channel modes. P1, P2, P3, P4, P5, P6, P7 mode can be chosen
Control Mode: DMX-512, auto, master&slave
Auto Effect: 7 kinds of static effect, 3 kinds of dynamic effect
Control Address Code: 512 DMX, 255 ID
Optical System
Dimmer: From 0~100 linear dimming
Strobe: 1~20Hz
Beam Angle: 25° (Or 15°)
Lens: Honeycomb type high transparent PMMA second optical lens
Physical
Dimensions: 930 x 76 x 135 mm
Net Weight: 3.7 kg
Surface Treatment: Stretched aluminum, the surface anodic oxidation
Housing Color: Silver (Can be customized)
Connection: DMX cable IN/OUT, POWER cable IN/OUT
Security
Cooling System: Convection
Temperature Protection: 65°C
Waterproof Grade: IP65
Operating Environment: Indoor / Outdoor
Working Temperature: -20°C～40°C
Optional Accessories: Yoline LED controller (YO-LD008-1A)
