Power supply
Voltage: AC90~240V
Frequency: 50~60Hz ± 10%
Power: 100W
Circuit System: Constant current drive, over-current protection and over-temp protection
LED
LED Type: 7×12Watt OSRAM RGBW 4IN1 full color super bright LED
Drive Current: 700mA
Colors: 16.7 million colors (0~100% saturation dimming)
Life: 50,000 hours
Control
Control Protocol: International standard DMX-512 signal
Channel: 15CH
Control Mode: DMX-512, auto, master&slave and LCD
Optical System
Dimmer: From 0~100 linear dimming
Strobe: 1~18Hz
Lens: PMMA OSRAM specialied convex optical lens
Beam Angle: 8°
Operation
Pan: 540°
Tilt: 270°
Physical
Dimensions: 152(D) x 265(W) x 310(H) mm
Packing Size: 260(D) x 320(W) x 335(H) mm
Net Weight: 4.9 kg
Gross Weight: 5.7 kg
Surface Treatment: ABS engineering clinker, high strength aluminum plate, powder coating
Housing Color: Black (Can be customized)
Connection: DMX cable IN/OUT, POWER cable IN
Security
Cooling System: Fan
Waterproof Grade: IP20
Operating Environment: Indoor
Working Temperature: -20°C～40°C
