Power supply
Voltage: AC90~240V
Frequency: 50~60Hz ± 10%
Power: 350W
Circuit System: Constant current drive, over-current protection and over-temp protection
LED
LED Type: 36×10Watt RGBW 4IN1 full color super bright LED
Drive Current: 500mA
Colors: 16.7 million colors (0~100% saturation dimming)
Life: 50,000 hours
Control
Control Protocol: International standard DMX-512 signal
Channel: 14CH
Control Mode: DMX-512, auto, master&slave and LCD
Optical System
Dimmer: From 0~100 linear dimming
Strobe: 1~18Hz
Lens: PMMA texture convex optical lens
Beam Angle: 15°~60°
Operation
Pan: 540°, 16 bit smooth, position scanning memory and automatic error correction
Tilt: 265°, 16 bit smooth, position scanning memory and automatic error correction
Physical
Dimensions: 229(D) x 330(W) x 437(H) mm
Net Weight: 11 kg
Surface Treatment: ABS engineering clinker, high strength aluminum plate, powder coating
Housing Color: Black (Can be customized)
Connection: DMX cable IN/OUT, POWER cable IN
Security
Cooling System: Fan
Waterproof Grade: IP20
Operating Environment: Indoor
Working Temperature: -20°C～40°C
