       - Light Source
LED Qty.: 16 x 6W RGBWA+UV
Drive Current: 400mA
Color Range: 16.7 million additive RGB colors with full saturation control (0-100% saturation dimming)
Electrical
Input Voltage: DC16.8V 2A
Max. Power: 120W (MAX)
Battery Life: 15 hours (MAX)
Control
Control Mode: Wireless DMX-512, Infrared remote control, Mobile APP
Protocol:DMX512
Channel mode: 2 kinds control channels mode
Communication Distance: 100M (it changes vary with different environments)
Optical System
Dimmer: From 0~100 linear dimming
Flashing rate: 1~20Hz
Beam angle: 15° or 25° or 40°
Lens: Honeycomb type high transparent PMMA second optical lens
Physical
Dimensions: 170 x 170 x 185mm
Weight: 4.3Kg
Housing: Die-cast aluminium, powder-coated finish
Color: Black
Fixture Connection: DMX Data in/out
Cooling: Thermal Convection
Certification and Safety
Operation Temperature:-10 C°~40C°
Over heat protection temp: 65C°
Waterproof class: IP65
Operation environment: Outdoor
|
