      - Electrical
Input Voltage: 100~240V 50/60Hz
Max. Power: 600W (MAX)
Light Source
LED Qty.: 120 x 4in1 RGBW10W
Drive Current: 500mA
Color Range: 16.7 million additive RGB colors with full saturation control (0-100% saturation dimming)
Control
On-board:Display for Static Color/Auto/Custorn control
Protocol:DMX512
Channel mode: 5 kinds control channels mode. STAG mode, ARC2, AR2.d, AR2.S, 8CH mode can be chosen
Optical System
Dimming mode: Dimmer 0 means fast Linear dimming.Dimmer 1~8 stands for soft Non-linear dimming.
Dimmer: From 0~100 linear dimming.
Flashing rate: 1~20Hz
Beam angle: 15° or 25° or 40°
Physical
Dimensions: 760 x 380 x 820mm
Weight: 31.8Kg
Housing: Die-cast aluminium, powder-coated finish
Color: Black
Fixture Connection: Data in/out, Power in/out
Cooling: Thermal Convection
Certification and Safety
Operation Temperature:-10 C°~40C°
Over heat protection temp: 65C°
Waterproof class: IP65
Operation environment: Outdoor
|
