Power supply
Rated Voltage: AC90~240V
Rated Frequency: 50~60Hz ± 10%
Rated Power: 250W (Max)
LED
LED Type: 15pcs ×15W Cool+Warm white 2in1 super bright LED
Drive Current: 1500mA
Color Temperature: 2700 ~6500K
Life: 50000 hours
Control
Control Protocol: International standard DMX-512 signal
Channel Protocol: 6 kinds control channels mode. STAG; CW; CW.D; CW.C; CW.S; 6CH mode can be chosen.
Control Mode: DMX-512,auto,master-slave.
Auto Effect: 2 kinds of auto effect
Optical System
Dimming mode: Dimmer 0 means fast Linear dimming.Dimmer 1~8 stands for soft Non-linear dimming.
Dimmer: From 0~100 linear dimming.
Refresh rate: 15KHz
Flashing rate: 1~20Hz
Beam angle: 10°~60°
Lens: Vertical structure light guide column + aspheric optical lens
Physical
Dimensions: 331 x 240 x 325 mm
Weight: 8.1kg
Surface treatment: Die-casting aluminum,
high temperature black paint
Housing color: Black (Can be customized)
Connection: Signal cable IN/OUT, power cable IN/OUT.
Security
Cooling System: Convection
Waterproof Rate: IP65
Temperature Protection: 65℃
Operating Environment: Indoor / Outdoor
Working Temperature: -10°C～40°C
